1.Design 6 pieces U beam design
2.U beam thickness design with 6mm
3.Pre camber machine to making platform have a high curves in Middle of platform
4.Auto welding machine to ensure welding is smooth and good strength
5.Shot blasting clean all dirty before painting
Product Description
1. Width with 3m/3.2m/3.4m/3.5m/4m
2. Lenth with 7m/8m/9m/10m/12m/15m/16m/18m/20m/21m/22m/24m
3. Capacity:10ton/20ton/30ton/40ton/50ton/60ton/80ton/100ton/120ton/150ton/200ton
4.Application:Weighing steel,concrete,mining,recyclying,chemical,grain etc industry
5. Certification: ISO9001, CE, OIML, NTEP
|
Product description & specification |
|
|
Width |
3m,3.2m.3.4m,3.5m,4.5m |
|
Length |
6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,22m,23m,24m |
|
Accuracy class |
OIML(III) |
|
Max Capacity range |
10-200(Ton) |
|
Safe overload |
150% |
|
Painting |
Anti rust and anti corrosion painting |
|
Work temperature |
Indicator:-10°C to +40°C Scale platform: -30°C to +65°C |
|
power supply |
220V 60HZ or 110V 60HZ(AC and DC) |
|
Packing detail |
Carton packing |
|
Quality system |
ISO9001:2008 |
|
Certificate |
04809Q11426R0M |
|
Standard accessory part include: |
|
|
Weighing indicator |
Analog type or digital type(Stainless surface with LED OR LCD) |
|
Load cell/sensor |
High accuracy load cell(Rate load 30ton) |
|
Printer |
Epson Brand optional(Use print out weight bill) |
|
Junction boxes |
Stainless Waterproof type junction boxes (IP68) |
|
Connect cable |
50M(depends on the distance from scale house to scale) |
|
Screw |
8.8 class high strength Bolts-screws,limit screw,loading cell screw,cover plate screw |
|
Installation tools |
Inner six angle spanner,Uncrock spanners,Screwdriver. |
|
Optional accessory part include: |
|
|
Scoreboard |
Convenience for seeing weighing result in the long distance.(LED) |
|
Weighing management software |
Install software in PC and operate the truck ID,tare,net,gross,accumulation etc intelligence automatic system. |
|
PC |
Brand desktop computer |
|
Protect rail |
Use warm and protect safe weighing |
|
Steel ramps |
Use convenient for truck drive on scale weighing |
|
Note |
Other optional part:Camera,traffic light,fence,etc |
